Impressive in every respect

The M18 is a premium spotlight with 1,200W multispectral LED for particularly intense color applications in drama, theatre and opera settings. Thanks to its immense luminosity (e.g. 25,000 lm output at 5800 K), it provides breathtakingly bright light projections even from a great distance.

The M18 equipment package is also impressive and leaves nothing to be desired: including 14 projection gobos, a fully-fledged animation wheel, 2 prisms, 2 frost filters and a 130° rotatable framing module.

Technical data

Optics and light source

1,200 W RGBYA LED module
42.900 lm (25.000 lm Output at 5800 K); CRI 95
> 20,000 h life time
Flicker-free operation, camera mode: 100, 120, 600 Hz and 3 kHz
Zoom range: 6.5° – 54° (1:8.3)

Effects

1 gobo wheel with 8 static, interchangeable gobos + open
1 gobo wheel with 6 rotate-, position- and interchangeable gobos + open
CMY, RGB and RGBYA color mixing
CRI adjustable from 80 to 95
The white light color temperature is seamlessly adjustable from 2000 to 20,000 Kelvin
Framing module with 4 blades – each with separate motion and rotation control, the module can be rotated by 130° (+/- 65°), each blade independently by +/- 30°
Endlessly rotating animation wheel for water and fire effects
Motorised infinitely adjustable high-speed iris with 18 fins
1 prism, 3-section circular, rotate- and indexable
1 prism, 5-section linear, rotate- and indexable
2 frost filters (soft edge/flood frost), continuously variable – optional further frost stages possible
Electronic dimmer 0%–100%
Electronic shutter with preprogrammed puls- and ramp functions
Animation effect
Focus system with auto focus function
Zoom range: 6.5°–54° (1:8.3)

Movement

3 phase extra strong stepping motors
Precise, very fast and silent movement
540° pan / 280° tilt

Control and programming

USITT DMX-512, RDM
Ethernet / Artnet - sACN
Wireless DMX / RDM Lumen Radio CRMX TiMo
Bluetooth, Wifi
LCD-display with function keys and batterie backup
Mini USB for software update
Stand-alone mode
Master/slave function
Built-in DMX analyser

Construction

Original JB-Lighting slide-in module technology
Rugged construction
Transport lock for pan/tilt
Fan control for almost noiseless operation, 28 dB(A)
Neutrik 5pin IN/OUT
Neutrik etherCON IN/OUT
Neutrik powerCON TRUE1 IN/OUT

Rigging

2 Omega brackets with Original Camloc® fasteners for quick and convenient installation with four different fastening options

Electrical specification

Max. power consumption 1,600 VA
Input voltage range 100 – 240V, 50/60HZ

Mechanical specification

Dimensions: W 475 x H 755 x D 307 mm
Weight: 32 kg

Scope of delivery

Schuko on powerCON TRUE1,
flexible rubber cable (2 m long, 3 x 1.5 mm²)
2 Omega brackets

FRAMING MODULE

The M18 Profile is equipped with a 130° rotatable framing module. This allows the round shape of the beam to be limited for targeted shading, creating a variety of geometric shapes for partial illumination. The blades can be pushed in along the entire travel path with the maximum angle of +/- 30°, which is particularly important for very steep shading angles.

Blades can be pushed in the same distance

Module +/- 65° rotatable

Each blade approx. +/- 30° rotatable

Accurately positionable

BRILLIANT COLORS

When it comes to color, there's no mistaking the M18 Profile – because thanks to multispectral, additive colour mixing, colors are reproduced in a variety and brilliance that is simply outstanding. Furthermore, the CRI 95 of the M18 makes skin tones in particular appear completely natural and the white light color temperature is variable and continuously adjustable from 2000 to 20,000 Kelvin. The M18 comes complete with a whole range of pre-programmed white, color and pastel tones.

ZOOM RANGE

The optical system of the M18 Profile guarantees extremely sharp and unvarying beams of 6.5° – 54° (1:8.3) – regardless of light intensity and beam angle.

Minimum zoom

Maximum zoom

PRISMS

Gobos and shutter blades can be combined with two prisms – 3-section circular or 5-section linear – also rotating at different speeds.

3-section prism (circular)

5-section prism (linear)

ANIMATION WHEEL

Dynamic fire and water effects can be created at different rotational speeds thanks to the endlessly rotating animation wheel.

Fire effect

Water effect

FROST FILTERS

The continuously adjustable frost filters (1°, 5°) make the M18 a versatile stage pro that can also be used for particularly color-intensive wash effects.

Soft edge, 1°

Flood frost, 5°

Gobos

The M18 Profile is equipped with two gobo wheels that can be easily removed if required (e.g. for cleaning or gobo replacement). One gobo wheel is equipped with 8 static gobos, the other with 6 rotating and position-adjustable gobos. The M18 Profile gobos have been specially assembled for projecting patterns, textures and backgrounds onto theatre stages.

ROTATING GOBOS

FIXED GOBOS

That works!

Real bespoke work – the perfect accessory for the M18 Profile
„Made in Germany“

SINGLE FLIGHT CASE

AMPTOWN (Code CASE31)

Pro case made from 10 mm birch plywood with SiP insert, stacking troughs and a scan window
Original amptown cases Blue Wheels
Dimensions: W 60 x D 58 x H 86 cm
Weight without (incl. fixtures): approx. 48 (80) kg

DOUBLE FLIGHT CASE

AMPTOWN (Code CASE32)

Pro case made from 10 mm birch plywood with SiP insert, stacking troughs and a scan window
Original amptown cases Blue Wheels
Dimensions: W 120 x D 58 x H 86 cm
Weight without (incl. fixtures): approx.74 (138) kg
